XM 电动液压旋铆机 XM SERIES SPINNING RIVETTER
XM电动液压旋铆机是依据冷辗原理研制而成的新型铆接设备。工作时铆钉压力仅为压铆的1/10铆后工件无不良变形，铆接表面光洁美观，生产效率高。是一款独特的复合铆接设备。
XM 电动液压旋铆机 XM SERIES SPINNING RIVETTER
XM电动液压旋铆机是依据冷辗原理研制而成的新型铆接设备。工作室铆钉压力仅为压铆的1/10铆后工件无不良变形，铆接表面光洁美观，生产效率高。是一款独特的复合铆接设备。
Rivetting machine of XM servies are new-style rivetting equipments, they are developed according to the principle of cold roll. Low forming pressure of rivet, which is only 1/10 of rivetting punch. Work piece has no adverse deformation, high somooth finish and high productivity after rivetting.
|
机型
Model |
最大铆接直径
Max rivetting
diameter |
最大铆接压力
Max.rivetting force |
最大主轴行程
Max. travel
of spindle |
铆头到工作台最大距离
Distance between tool head and stable |
工作台尺寸
Work table size |
外形尺寸
Overall dimensions |
|
XM5 |
5mm |
8.5KN |
20mm |
120mm |
120mm |
440X320X822 |
|
XM8 |
8mm |
13KN |
30mm |
275mm |
250mmX200mm |
700X500X1477 |
|
XM10 |
10mm |
19KN |
30mm |
275mm |
250mmX200mm |
700X500X1500 |
|
XM16 |
16mm |
34KN |
50mm |
220mm |
350mmX250mm |
800X585X1850 |
|
XM20 |
20mm |
65KN |
30mm |
250mm |
420mmX300mm |
1070X500X1930 |
|
XM30 |
30mm |
100KN |
30mm |
300mm |
500mmX355mm |
1300X580X2200 |
